TECHNICAL DATA

  • Electrical Requirement: 3/60/208-230-460 VAC @ 17-15-7.5 amps



  • Make-up water: 20 gpm @ maximum 80ºF


For more information on our Tumbler-Chiller, please contact our office at 1-800-685-3750

FUNCTION

To quickly, efficiently and safely chill hot foods packaged in flexible pouches



FEATURES

  •  Single rotating, perforated, stainless steel product containment drum, bi-parted into dual compartments, both accessible for front loading and unloading



  • Fully insulated stainless steel chilled water reservoir including stainless steel water circulating pump with integral strainer and level control



  • Electric safety inter-lock, prevents access door from opening while drum is in motion



  • Integral stainless steel control panel with sequence timer, illuminated switches, motor starters, audio alarm and automatic control



  • Unique "Gentle Cycle" feature that accommodating tumble-chilling of even the most delicate food products



  • Large access door facilitates quick and efficient loading and unloading of product



  • Adjustable stainless steel ball feet for leveling



  • 160, 240 and 320 gallon product capacities available



BENEFITS

The segmented rotating drum of the Chester-Jensen Tumbler-Chiller allows the product pouches to be "kneaded" gently and continuously during the tumbling cycle, thereby moving hot product to bag surface to increase heat transfer efficiency, minimizing chill cycle time. Additionally, the waist-high final product access allows bags to drain with no accompanying loss of water while providing optimum operator ergonomics.



When combing the Tumbler-Chiller with a compatible heat exchanger, continuous ice water recirculation eliminates the  need for water refill after each batch.



All components are easily accessed, cleaned and inspected.



TYPICAL APPLICATIONS

Used in all types of meal production facilities including, but not limited to, central kitchens, institutional facilities (hospitals, schools, prisons, etc.), restaurants and resorts.

Tumbler-Chiller
